How Many Anchors do I Need for my Thermal Expansion Application?

Anchors for Thermal Expansion

The rules are:

1. To divide up the piping system into the largest sections a single joint can handle

2. Place anchors between the joints.

3. Review that the anchor locations are suable for the installation of an anchor. In line bellows expansion joints can develop high anchor loads.  See How do I calculate in line bellows anchor loads?

4. Only install one expansion joint between anchors.


Check out our Thermal Application guide for more information.
